TPD 32-120/4 A F A BQQE 0.55kW Single Stage Twin Head In Line 4 Pole 415v
BEST ONLINE PRICES
FREEPHONE 0800 112 3134 if you've seen it cheaper.
* Available where Guaranteed Stock Icon Appears Below
Grundfos TPD 32-120/4 A F A BQQE Single Stage Twin Head In-Line Pump with 4 Pole 415V 3Ph 50Hz, 0.55kW Motor and flanged pump connections.
Single-stage centrifugal in-line twin-head pump:
- neck rings and impeller made of cast iron
- cataphoresis treatment
- shell coupling
- top-pull-out principle for easy maintenance
- optimized hydraulics
- in-line design with opposite suction and discharge ports enabling mounting in pipework or on a concrete foundation
- corrosion resistant maintenance-free mechanical shaft seal.
- 32mm flanged
IMAGE FOR ILLUSTRATION PURPOSES ONLY.
| SKU | 96086759 |
|---|---|
| Manufacturers | Grundfos |
| Manufacturers Warranty | 2 Years |
| GTIN | 5700395307153 |
| Weight | 108.0 Kg |
| Dimensions | 487mm (h) x 642mm (w) x 440mm (d) |
| Connection Type | 32mm Flanged |
| Motor Size | 0.55 kW |
| Full Load Current (FLC) | 1.50 A |
| Voltage | 415V 3Ph 50Hz |
| RPM | 1400rpm |
| Max Flow | 13m3/hr |
| Max Head | 12m |
| Max Temperature | 120 degrees C |
| Material | Cast Iron |
| Impeller Material | Cast Iron |
