TPD 32-120/4 A F A BQQE 0.55kW Single Stage Twin Head In Line 4 Pole 415v

Name: TPD 32-120/4 A F A BQQE 0.55kW Single Stage Twin Head In Line 4 Pole 415v
Brand: Grundfos
SKU: 96086759
Price: 2407 GBP
Availability: InStock

SKU

96086759

MRRP £4,149.00 + VAT Our price £2,407.00 (+ VAT) Incl. VAT: £2,888.40

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Choose Flange Set Option

Choose Bellow Set Option

Choose Gasket Set Option

Qty

Order within

Hours

Mins

Secs

for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Overview & Spec

Grundfos TPD 32-120/4 A F A BQQE Single Stage Twin Head In-Line Pump with 4 Pole 415V 3Ph 50Hz, 0.55kW Motor and flanged pump connections.

Single-stage centrifugal in-line twin-head pump:

neck rings and impeller made of cast iron
cataphoresis treatment
shell coupling
top-pull-out principle for easy maintenance
optimized hydraulics
in-line design with opposite suction and discharge ports enabling mounting in pipework or on a concrete foundation
corrosion resistant maintenance-free mechanical shaft seal.
32mm flanged

IMAGE FOR ILLUSTRATION PURPOSES ONLY.

More Information
SKU	96086759
Manufacturers	Grundfos
Manufacturers Warranty	2 Years
GTIN	5700395307153
Weight	108.0 Kg
Dimensions	487mm (h) x 642mm (w) x 440mm (d)
Connection Type	32mm Flanged
Motor Size	0.55 kW
Full Load Current (FLC)	1.50 A
Voltage	415V 3Ph 50Hz
RPM	1400rpm
Max Flow	13m3/hr
Max Head	12m
Max Temperature	120 degrees C
Material	Cast Iron
Impeller Material	Cast Iron
