NBE 150-250/230 A F A E BQQE Single Stage Variable Speed End Suction 1450RPM 18.5kW Pump 415V

SKU
99105340
MRRP £17,459.00 + VAT Our price £12,222.00 (+ VAT) Incl. VAT: £14666.40

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within
09
Hours
38
Mins
16
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Grundfos NBE 150-250/230 A F A E BQQE Single Stage Variable Speed End Suction Bloc Pump with 4 Pole and 1450rpm Motor 415V 3Ph 50Hz, 18.5kW Motor

Single-stage end suction bloc pump:

  • Non-self-priming, single-stage, centrifugal volute pump designed according to ISO 5199 with dimensions and rated performance according to EN 733 (10 bar).
  • Flanges are PN 16 with dimensions according to EN 1092-2.
  • The pump has an axial suction port, radial discharge port, horizontal shaft and a back pull-out design enabling removal of the motor, motor stool, cover and impeller without disturbing the pump housing or pipework.
  • The unbalanced rubber bellows seal is according to DIN EN 12756.
  • The pump is close-coupled to a fan-cooled, permanent-magnet asynchronous motor.
  • For pumping thin, clean or lightly contaminated liquids without abrasive or long-fibred solids.
  • The motor includes a frequency converter and PI controller in the motor terminal box. This enables continuously variable control of the motor speed, which again enables adaptation of the performance to a given requirement.
  • Suitable for water supply, industrial pressure boosting, industrial liquid transfer, HVAC and irrigation.
  • 150mm outlet and 200mm inlet.
  • A flange kit comprising of two sets of flanges is required, see related accessories for options.
More Information
SKU 99105340
Manufacturers Grundfos
Manufacturers Warranty 2 Years
GTIN 5712606853311
Weight 377.0 Kg
Dimensions 1083mm (w) x 488mm (h) x 420mm (d)
Inlet Dimension 200mm Flanged
Discharge Dimension 150mm Flanged
Full Load Current (FLC) 30.0 A
Voltage 415V 3Ph 50Hz
RPM 1460rpm
Max Flow 450m3/hr
Max Head 15m
Max Temperature 120°C
Material Cast Iron
Impeller Material Cast Iron
