KSB AMA-Drainer 302 SE/NE N C Submersible Aggressive Liquid Pump 240V
BEST ONLINE PRICES
FREEPHONE 0800 112 3134 if you've seen it cheaper.
* Available where Guaranteed Stock Icon Appears Below
KSB AMA-Drainer 302 SE/NE N C Submersible Aggressive Liquid Pump 240V - 39300077
The Ama-Drainer N 302 SE/NE C is a submerisble pump from KSB capable of operating at an immersion depth of up to two metres.
The Ama-Drainer N 302 Se/NE C can handle waste water with dirt particles up to a particle size of 10mm. The maximum flow rate is 12 cubic metres per hour, the max head is 10 metres. KSB AMA-Drainer submersible motor pump are suitable for aggressive liquid applications such as Sea water, Vinegar, Swimming Pools, Lime water and Sodium Chloride upto 3% concentration.
Applications:
- automatic drainage of pits, shafts, yards and cellars that are prone to flooding
- lowering surface water levels
- drainage of underground passageway
- extraction of water from rivers and reservoirs
- general drainage of aggressive liquids (as listed in the PDF brochure)
Fluids Handled:
- faecal-free waste water
- grey water
- river, lake and groundwater
- seawater
- brackish water
- water containing salt
Materials:
- pump casing - Polypropylene, glass fibre reinforced (30%)
- discharge casing - Polypropylene, glass fibre reinforced (30%)
- casing cover - Noryl GNF3
- impeller - Noryl GNF2
- motor housing - Chrome nickel molybdenum steel (1.4571)
- float switch - Polypropylene
This pump has 1 1/4" BSP female discharge port and built in non-return valve.
| SKU | 39300077 |
|---|---|
| Weight | 7.2 Kg |
| Dimensions | 363mm High x 214mm Diameter |
| Manufacturers | KSB |
| Manufacturers Warranty | 2 Years |
| Material | Plastic |
| Impeller Material | Noryl GNF2 |
| Connection Type | 1 1/4 Inch BSP Female |
| Voltage | 240V 1Ph 50Hz |
| Max Flow | 3.5 l/s |
| Max Head | 10m |
| Full Load Current (FLC) | 4.0A |
| Motor Size | 0.18kW |
| Cable Length | 10 Metres |
| Float Switch | Yes |
| Immersion Depth | 2 metres |
