GWS Hydroguard 0.6L 1/2" BSP 1 Bar Pre-Charge Hydraulic Shock Arrestor

SKU
HGBSF-0.6LX-C0.50-1.0BAR
MRRP £29.00 + VAT Our price £17.00 (+ VAT) Incl. VAT: £20.40

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within
Hours
Mins
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

GWS Hydroguard 0.6L 1/2" BSP 1 Bar Pre-Charge Hydraulic Shock Arrestor - HGBSF-0.6LX-C0.50-1.0BAR

HydroGuard™ shock arrestors are specially built with the latest diaphragm technology designed to reduce and eliminate hydraulic shock. The internal diaphragm divides the arrestor into separate air and water chambers. The sealed air chamber acts as a cushion that compresses when the water pressure suddenly increases or surges due to hydraulic shock.

HydroGuard shock arrestors are best used at the point of shock and should be installed as close to the valve or piping where the shock originates. They are ideal for washing machine and dish washer installations, sinks and toilets, reverse osmosis systems and any other plumbing application where quick closing valves or fast-acting solenoid valves are installed.

HydroGuard shock arrestors are certified and approved for potable water systems and are drinking water safe. Each HydroGuard shock arrestor is quality tested at several stages along the production line to ensure the structural integrity and safety of every arrestor.

Features:

  • High grade butyl diaphragm
  • Adjustable pre-charged air pressure
  • Dual layer polyurethane paint finish
  • 1/2" BSP connection
  • 1 Bar factory pre-charge
  • Leak free O-ring sealed air valve
  • Comprehensive testing
  • Maintenance-free

Applications:

  • Booster systems
  • Plumbing installations (for example toilet, washing machine, dishwasher)
  • Commercial bathrooms and sinks
  • Solenoid valve protection
More Information
SKU HGBSF-0.6LX-C0.50-1.0BAR
Manufacturers GWS
Manufacturers Warranty 1 Year
Weight 0.6 Kg
Dimensions 159mm (h) x 97mm (w)
Connection Type 1/2 Inch BSP
Max Pressure 10 Bar
Max Temperature 90°C
