DAB JetCom SP 102 T-IE3 Swimming Pool Pump 415v

SKU
60181157
MRRP £386.00 + VAT Our price £271.00 (+ VAT) Incl. VAT: £325.20

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within
Hours
Mins
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

APPLICATIONS
Self priming centrifugal pump with excellent suction capacity even in the presence of air bubbles. Suitable for pumping water with low levels of sandy impurities. Especially used in domestic water supply installations. Suitable for small farms and gardening, small scale industrial services and where self priming is necessary.

CONSTRUCTIONAL FEATURES OF THE PUMP
Pump body in technocpolymer and motor support in die cast aluminium.
Impeller, diffuser, venturi tube and sand guard in technopolymer.
Stainless steel wear ring.
Carbon/ceramic mechanical seal.

CONSTRUCTIONAL FEATURES OF THE MOTOR
Asynchronous type, closed, with external air cooling. Rotor mounted on oversized greased-for-life ball bearings, to guarantee low noise and long life. Incorporated thermo-amperometric protection and permanently inserted capacitor in the single phase version. It is recommended to use overload protection for three phase motor protection, in compliance with current legislation. Manufactured pursuant to CEI 2-3 and CEI 61-69 (EN 60335-2-41).

More Information
SKU 60181157
Manufacturers DAB
Manufacturers Warranty 2 Years
Weight 10.0 Kg
Dimensions 203mm (h) x 425mm (w) x 170mm (d)
Connection Type 1 Inch BSP Female
Motor Size 0.75kW
Full Load Current (FLC) 3.3-1.9A
Voltage 415V 3Ph 50Hz
Max Flow 4.5m3/hr
Max Head 56m
Max Pressure 5.6 Bar
Max Temperature 35°C
Material Cast Iron
