DAB FEKAFOS 2200 MAXI - DN80 + CV80 Draining Tank with Valve Chamber + Filter Grill + Anti-Intrusion Grid
BEST ONLINE PRICES
FREEPHONE 0800 112 3134 if you've seen it cheaper.
Fekafos Maxi Tank with valve chamber, filter grill and anti-intrusion grid.
APPLICATIONS:
Automatic collection and lifting station suitable for clear and rainwater or civil and industrial waste. Composed of a cylindrical polyethylene monoblock with a suitably shaped bottom to house the pumps and to avoid stagnation. The upper inlet is equipped with lids with locking clasps and anti-odour seals. The station is set up for the use of two single-phase non-automatic or three-phase pumps with a discharge diameter from DN50 to DN80.
CONSTRUCTION CHARACTERISTICS:
CAPACITY: 1200 / 1700 / 2200 / 3600 L
MATERIALS: High density polyethylene
CONNECTIONS:
• DN DN125 / DN160 inlets
• DN 50 ventilation
• 2xDN50 / 2xDN65 / 2xDN80 outlets
COMPONENTS INCLUDED:
• 2 coupling units in grey cast iron for insertion and extraction of pumps
• stainless steel guide tubes
• PVC “T” inlet fitting
• 2 polyethylene outlet pipes
• 3 Bulb floats
• Lids with locking clasps and polyethylene anti-odour seals
ACCESSORIES ON REQUEST:
• Valve inspection section complete with two gate valves and grey cast iron check valves
• Anti-intrusion grating.
• Filter basket
• Drive-over frame D400 1200x1200 (To be fixed on site in the concrete structure surrounding the tank)
SKU | 60190461 |
---|---|
Manufacturers | DAB |
Manufacturers Warranty | 2 Years |
Weight | 220.0 Kg |
Dimensions | 2320mm x 1500mm (Height x Width) |
Inlet Dimension | DN160 |
Discharge Dimension | DN80 |
Material | Plastic |
Country of Manufacture | Italy |
