DAB ALM 500 M In-Line Circulator 240v
BEST ONLINE PRICES
FREEPHONE 0800 112 3134 if you've seen it cheaper.
* Available where Guaranteed Stock Icon Appears Below
APPLICATIONS
Hot or cold water circulation pump with in-line ports, suitable for installation directly on the pipework of civil and industrial heating, air conditioning, refrigeration, and sanitary water systems.
CONSTRUCTION FEATURES OF THE PUMP
Cast iron pump body and motor support for ALM 500 and ALP 2000, bronze for ALM 200 and ALP 800. 1” 1/2 M-GAS suction and delivery ports for ALM 200 and ALP 800, and 2” M-GAS for ALM 500 and ALP 2000. Technopolymer impeller. Carbon/ceramic mechanical seal.
CONSTRUCTION FEATURES OF THE MOTOR
External ventilation cooling, closed, asynchronous type, with four poles for the ALM version, and two poles for the ALP version. Rotor running on permanently lubricated ball bearings, oversized to ensure low noise and durability.
Standard built-in thermo-amperometric protection. Capacitor permanently fitted on single phase versions.
For the protection of the three-phase motor, we recommend the use of remote overload cut-outs, in compliance with current local regulations. Construction according to CEI 2-3.
Protection class: IP 55
Insulation class: F
Standard voltages: single-phase 220-240V 50Hz.
three-phase 230/400V 50Hz
| SKU | 105100024 |
|---|---|
| Manufacturers | DAB |
| Manufacturers Warranty | 2 Years |
| Weight | 15.0 Kg |
| Dimensions | 386mm (w) x 235mm (h) x 174mm (d) |
| Connection Type | 2 Inch BSP Male |
| Motor Size | 0.25kW |
| Full Load Current (FLC) | 1A |
| Voltage | 240V 1Ph 50Hz |
| RPM | 1425rpm |
| Cable Length | 1.5m |
| Max Flow | 8m3/hr |
| Max Head | 6m |
| Max Temperature | 120°C |
| Material | Cast Iron |
