Calpeda NM 32/12AE Flanged End Suction Pump 415V

Name: Calpeda NM 32/12AE Flanged End Suction Pump 415V
Brand: Calpeda
SKU: NM32/12AE
Price: 547 GBP
Availability: InStock

SKU

NM32/12AE

MRRP £781.00 + VAT Our price £547.00 (+ VAT) Incl. VAT: £656.40

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within

Hours

Mins

Secs

for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Overview & Spec

Calpeda NM 32/12AE flanged close coupled end suction centrifugal pump with 1.1kw (1.5HP) 415V 3Ph 50Hz Motor - NM32/12AE

Calpeda NM flanged end suction close-coupled centrifugal pumps have an electric motor with shaft directly connected to the pump.

These pumps are suitable for the following applications:

Clean liquids without abrasives, which are non-aggressive for the pump materials (solids content up to 0.2%)
Mains water supply
Heating, air conditioning, cooling and circulation
Civil and industrial applications
Fire fighting applications
Irrigation

More Information
SKU	NM32/12AE
Manufacturers	Calpeda
Manufacturers Warranty	1 Year
Weight	25.0 Kg
Dimensions	405mm (d) x 252mm (h) x 190mm (w)
Inlet Dimension	50mm Flanged
Discharge Dimension	32mm Flanged
Motor Size	1.1 kW
Full Load Current (FLC)	2.7A
Voltage	415V 3Ph 50Hz
Max Flow	15m3/hr
Max Head	23m
Max Temperature	90°C
Material	Cast Iron
