ABS Piranha S21/2D EX Submersible Grinder Pump Without Floatswitch 415v

ABS Piranha S21/2D EX Submersible Grinder Pump Without Floatswitch 415v - PR3231111312111

Submersible pumps for problem-free pumping of sewage containing faecal matter in pipe lines from 1¼” (DN 32). Piranha submersible pumps have been designed for effective and economic dewatering using discharge lines of small diameter, in private, municipal and industrial areas. The water pressure-tight, encapsulated fully flood-proof motor and the pump section form a compact, robust, unit construction. The stainless steel motor shaft is supported in lubricated-for-life ball bearings.

Features:

• Unique Piranha shredding system capable of shredding items such as cloths and plastic bags
• For the pumping of wastewater containing sewage, offal, organic and industrial effluent
• Piranha 08 and 09 fitted with MF modular motor
• Small discharge lines from 1¼” (DN 32)
• Installations are possible where large ground undulations are present
• Low installation costs due to small diameter discharge pipework
• Spiral bottom plate and stationary cutter ring combined witha shredding rotor located before the impeller, for optimum blockage-free running
• : Piranha-S has been designed for intermittent use only (S3, 25%) when dry-installed, and continuous use (S1) when submerged
• Explosive-proof version in accordance with international standard ATEX 2 1G Ex db 11B T4 Gb

Applications:

• Sewage removal from living units and houses in remote settlements where the laying of a conventional sewer would be too expensive, where large ground undulations are present or where it is only possible to lay pipe lines of small diameter
• Sewage removal from motorway resting sites, communal buildings and for renovation of buildings or areas of a city
• For use in slaughter houses, food processing plants, paper factories, agriculture and similar areas
• Maximum allowable temperature of the medium is 40 °C, or short term to 60 °C (max. 5 minutes)
