ABS MF 334-10m KS Submersible Pump With Floatswitch 415v

Name: ABS MF 334-10m KS Submersible Pump With Floatswitch 415v
Brand: ABS
SKU: 01399135
Price: 839 GBP
Availability: InStock

SKU

01399135

MRRP £1,400.00 + VAT Our price £839.00 (+ VAT) Incl. VAT: £1,006.80

BEST ONLINE PRICES

FREEPHONE 0800 112 3134 if you've seen it cheaper.

Order within

Hours

Mins

Secs

for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Overview & Spec

ABS MF 334-10m KS Submersible Pump With Floatswitch 415v - 01399135

Compact submersible pumps with large solids passage for the reliable and effective dewatering of buildings and sites. The water-tight, fully flood-proof cast iron motor and the hydraulics section comprise a compact, robust, unit construction. The stainless steel motor shaft is supported in lubricated-for-life ball bearings.

Features:

Simple, cost-effective, pump installation
Vortex hydraulics for blockage-free pumping in critical applications
Free-standing on legs or pedestal mounted
Mechanical and lip seals on rotor shaft
KS version with float switch for automatic level control
Thermal sensors to protect motor against overheating
EasyFit plug-in cable connection
Three-phase fitted with CEE plug

Applications:

Filling and emptying of containers to the drainage of flooded cellars and removal of rainwater
Suitable for use in septic tanks and pumping effluent from locations below the backwash level in accordance with EN 12056
The compact shape of the MF, fittings for easy mounting, and small sump requirements ensure a quick and cost-effective installation of the pump

More Information
SKU	01399135
Manufacturers	ABS
Manufacturers Warranty	1 Year
Weight	9.0 Kg
Dimensions	350mm (h) x 199mm (w) x 133mm (d)
Connection Type	1 1/2 Inch BSP Female
Motor Size	P2 = 0.56kW
Full Load Current (FLC)	1.4A
Voltage	415V 3Ph 50Hz
RPM	2900rpm
Cable Length	10 metres
Float Switch	Yes
Max Flow	18m3/hr
Max Head	10m
Max Temperature	40°C, or short term up to 60°C (max. 5 minutes)
Material	Cast Iron
Impeller Material	Polyamide
