25mm (1") Rubber Expansion Joint Set (x2) for Heating Systems
BEST ONLINE PRICES
FREEPHONE 0800 112 3134 if you've seen it cheaper.
* Available where Guaranteed Stock Icon Appears Below
Designed to accommodate vibration and thermal expansion and to prevent the transmission of noise in pipework associated with hot water heating systems
Max Operating Conditions
- 10BarG @ 50oC
- 8BarG @ 70oC
- 5BarG @ 90oC
Minimum Operating Temp: -10oC
Test Pressure: 15BarG @ Ambient Temp
Bellow Length 203mm face to face
Construction Materials
Please note removal of the carbon steel support ring will reduce the integrity of the assembly and invalidate the warranty. These joints require the pipework to be securely anchored and guided for safe and correct operation
NOT Suitable for secondary domestic hot water
| SKU | FGTU025BSP |
|---|---|
| Weight | 3.5 Kg |
| Dimensions | 203mm length face to face |
| Manufacturers | Anchor |
| Max Pressure | 10BarG @ 50oC |
| Max Temperature | 90oC @ 5BarG |
| Connection Type | 1 Inch BSP Female |
| Suitable For Heating | Yes |
